XT24 Suspended Ceiling Main Tee 2.4m

The XT24 2.4m Suspended Ceiling Main Tee uses a fast-fit click-and-lock system that delivers quick, secure, and accurate installation.

You can easily connect each main tee to additional grid sections, allowing you to span suspended ceilings of any size with ease.

This grid section includes pre-punched hanging holes, so you can suspend it directly from the structural ceiling using 2mm galvanized ceiling wire or rigid galvanized metal angle. This ensures a stable and durable ceiling framework.

Every main tee comes with regular female fixing points, so you can quickly attach either 600mm or 1200mm XT24 cross tees.

This setup lets you create a suspended ceiling layout of 600 x 600mm or 1200 x 600mm, ready for ceiling tile installation.

The XT24 Suspended Ceiling Main Tee 2.4m x 24mm Grid Section works seamlessly with other XT24 grid components, including 600mm and 1200mm cross tees.

Together, they make it easy to build a strong, professional-quality 6 x 6 or 12 x 6 suspended ceiling grid system.

Technical Specifications

• Product Name: XT24 Suspended Ceiling Main Tee
• Length: 2400 mm (2.4m)
• Width: 24 mm
• Material: Aluminium
• Finish(pre-painted): White
• Connection System: Fast-Fit Click-&-Lock Ends
• Hanging Points: Pre-Punched Holes For 2mm Galvanized Ceiling Wire Or Rigid Metal Angle
• Cross Tee Compatibility: XT24 600mm & 1200mm Cross Tees
• Tile Grid Layouts: 600 x 600 mm or 1200 x 600 mm
• Fire Rating: A2 (BS EN 13501-1)
• Moisture Resistance: Yes – Corrosion-Resistant Coating
• Applications: Commercial, Retail, Offices, Education, Healthcare, Residential
• Compliance: EN 13964 – Suspended Ceilings – Requirements & Test Methods

Installation Notes

The XT24 Main Tee should be suspended from the structural soffit using 2mm galvanized ceiling wire or rigid galvanized angle.

Ensure hangers are spaced in accordance with ceiling grid layout requirements.

Attach cross tees at regular fixing points to form 600 x 600 mm or 1200 x 600 mm modules.

Storage & Handling

• Store flat in a dry environment, protected from moisture and dust.
• Handle with care to avoid bending or damage to the click-and-lock ends.
• Do not stack heavy loads on top of grid components.
